NJP-1200

Capsule Automatic Filling Machine NJP-1200

 NJP-1200 is dependable for hard capsule filling in diverse industries, performing processes such as capsule separation, filling, and locking.

Capsule SamplesCapsule

NJP-1200 Download

Capsule Automatic Filling Machine Features

Fully Enclosed Turntable: The ten-station turntable is enclosed, facilitating easy cleaning, preventing contamination, functioning smoothly, and operating precisely.

Advanced Measuring Disc: The measuring disc’s three-dimensional adjustment mechanism guarantees even gaps and minimizes powder leakage, thereby enhancing the filling accuracy rate.

Modular Design: The modular and standardized powder filling mechanism allow for easy disassembly and cleaning.

High-Precision Transmission: The machine’s high-precision transmission mechanism reduces vibrations and enhances operational stability, thereby extending the service life.

High Quality Control Components: Equipped with superior quality control components with an intuitive and dust-proof interface to realize safety

Capsule Automatic Filling Machine Specifications

ModelNJP-1200
Output72000Grain/hour
Machine weight1100Kg
Machine  Dimensions870(+339)mm*940(+339)mm*2000mm
Power Supply380/220V   50Hz
Motor power5.6KW（Standard）
No.of segment  bores9holes
VacuumExtraction rate48m3/h -0.03~-0.05Mpa
Dust20Kpa  210m3/h
Noise<75DB（A）
Making rateEmpty capsules99.8%  Full Capsule99.8%
Suitable for  Capsule000、00、0，1，2，3，4、5#
Filling error±3.5%-±4.5%

Machine Details

Broadcasting device

Broadcasting device
The bag spreading device accurately spreads pills

Easy disassembly

Easy disassembly
Simple structure, easy to replace components

Sowing Rack

Powder filling structure
Accurately fill the medicine powder into the capsule

Reject

Reject
Maintaining quality control and efficiency.

Vacuum material inlet

Vacuum material inlet
Minimizing contamination and enhancing processing accuracy.

Rotary table

Rotary table
Enables smooth and precise circular movement for various machining applications.

Capsule Automatic Filling Machine FAQS

1What is the Capsule Automatic Filling Machine NJP-1200?
The Capsule Automatic Filling Machine NJP-1200 is a high-performance machine designed to automatically fill capsules with powders, pellets, or other materials. It offers precision, speed, and efficiency, making it ideal for pharmaceutical and food industries.
2What are the key features of the NJP-1200 capsule filling machine?
The NJP-1200 comes with advanced features such as automatic capsule loading, powder filling, and capsule locking. It also offers easy operation through a user-friendly touch screen, adjustable filling speeds, and high production capacity.
3How fast is the NJP-1200 capsule filling machine?
The NJP-1200 capsule filling machine operates at high speed, filling up to 120,000 capsules per hour, making it highly efficient for large-scale production while maintaining precision and consistency.
4Is the Capsule Automatic Filling Machine easy to clean and maintain?
Yes, the NJP-1200 is designed for easy cleaning and maintenance. It features a modular design with quick disassembly, allowing for fast cleaning and minimal downtime between production cycles.
5Can the NJP-1200 fill different sizes of capsules?
Yes, the NJP-1200 is versatile and can fill various capsule sizes, from small to large. It is equipped with interchangeable parts that can be easily adjusted to accommodate different capsule specifications.
