Akışkan Yataklı Farmasötik Granülatör

Achieve unparalleled efficiency and consistency in your solid dosage manufacturing with Büyük state-of-the-art Fluidized Bed Granulator (FBG). Engineered for the demanding standards of the pharmaceutical, food, and chemical industries, this system seamlessly integrates mixing, granulation, and drying into a single, automated process. By combining these critical steps, our FBG technology dramatically reduces processing time, minimizes material handling, and lowers the risk of cross-contamination, delivering superior granule quality in a cGMP-compliant environment.

Detailed Description

Our Fluidized Bed Granulator is more than just a piece of equipment; it's a comprehensive solution for producing uniform, free-flowing granules with exceptional consistency. The process begins with our advanced air handling unit, which features a three-stage filtration system to ensure the process air is free of particulates, protecting the integrity of your product. With flexible electric or steam heating options, you can achieve precise temperature control, which is vital for reproducible results and protecting heat-sensitive active ingredients.

The "one-step" or "single-pot" granulation is performed in a closed system. Materials are loaded efficiently via a sealed, pressure-reduced feeding mechanism, ensuring containment and operator safety. Inside the product container, particles are fluidized by a carefully controlled upward stream of heated air. A high-precision nozzle sprays the binder solution onto the suspended particles, causing them to agglomerate and form granules. The process is continuously monitored and adjusted by the automated control system, ensuring optimal conditions from start to finish. Once granulation is complete, the system transitions to the drying phase in the same chamber, resulting in finished granules ready for the next stage of production.

Özellikler

Precision Process Control Our granulator provides exacting control over every critical parameter. An intuitive air intake control valve allows for fine-tuning of airflow and fluidization velocity, while the precision heating system maintains stable temperatures. This level of control results in consistent particle size distribution, bulk density, and flowability, batch after batch.

Intelligent Automation & Data Integrity (21 CFR Part 11 Ready) At the heart of the granulator is a powerful PLC system coupled with a user-friendly Human-Machine Interface (HMI). This provides complete automation and real-time monitoring of the entire granulation process. The system is designed for compliance, allowing you to easily store, export, and print critical process parameters and batch data, ensuring a clear audit trail for regulatory requirements.

Automated Cleaning for Maximum Uptime Minimize downtime between batches with our optional single-channel or multi-channel Wash-In-Place (WIP) automatic cleaning system. This fully automated cycle ensures thorough, repeatable, and validatable cleaning, freeing up operator time and getting you ready for the next run faster.

Özellikler

Sıkıştırılmış hava:0,4-0,7 MPa
Taslak Vantilatör:18,5 kW
Sertifikasyon:CE, ISO
Gerilim:380V
Şartname:3300x2300x2900mm
Konteyner Hacmi:22-1500L
Kapasite:5-500 Kg/Parti
Ekipman Malzemesi:çelikpaslanmaz çelik 304,316
Ağırlık:1300kg

Uygulamalar

  1. Pharmaceutical: Perfect for creating uniform granules for tableting and capsule filling, improving compressibility and dosage uniformity. Widely used for both immediate-release and controlled-release formulations.
  2. Food & Nutraceutical: Ideal for producing instant drink mixes, soup powders, seasonings, and dietary supplements that require excellent solubility and flow properties.
  3. Chemical: Efficiently granulates pigments, detergents, fertilizers, and other chemical compounds to improve handling, reduce dust, and ensure consistent product quality.

Makine Detayları

Kurutma ünitesi

Kurutma ana bilgisayarı
Paslanmaz çelik dolum tankı içerir

Nozul

Nozul
Yüksek hassasiyetli nozul, 304 paslanmaz çelik

SSS

İşte bazı SSS'ler
1Akışkan Yataklı İlaç Granülatörünün temel amacı nedir?
Bu granülatör, farmasötik katıların tek bir makinede karıştırılması, granüle edilmesi ve kurutulması için kullanılır.
2Hava filtreleme sistemi nasıl çalışır?
Makine, giriş havasını temizlemek için üç aşamalı bir filtre sistemi kullanıyor ve böylece temiz ve verimli bir işlem sağlıyor.
3Hangi ısıtma seçenekleri mevcut?
İhtiyaçlarınıza göre giriş havası için elektrikli ısıtma veya buharlı ısıtma arasında seçim yapabilirsiniz.
4Granülatör farklı malzemeleri işleyebilir mi?
Evet, çeşitli malzemelerle çalışabilir ve verimliliği koruyup çapraz bulaşmayı önleyecek şekilde tasarlanmıştır.
5Sıcaklık kontrolü ne kadar hassas?
Granülatör, optimum granülasyon ve kurutma için hassas ayarlara olanak tanıyan hassas sıcaklık kontrolü sunar.
6Granülatörün kapasite aralığı nedir?
Makine 5 ila 500 kg arası parti büyüklüklerini işleyebiliyor ve farklı üretim ihtiyaçlarına cevap verebiliyor.
7Granülatör endüstri standartlarına uygun mu?
Evet, FDA ve GMP standartlarına göre sertifikalandırılmış olup, yüksek kaliteli üretim gereksinimlerini karşıladığını garanti altına almaktadır.
8Granülatörün temizlenmesi kolay mıdır?
Evet, kolay bakım ve temizlik için isteğe bağlı tek kanallı veya çok kanallı WIP otomatik temizleme sistemlerine sahiptir.
