Small Vacuum Mixer Homogenizer DG-10L
The Small Vacuum Mixer Homogenizer could apply to process multiple raw materials and generate high quality outputs. The entire operation process is sanitary, precise, and efficient.
Features
Versatile and Widely Applicable: It integrates homogenization, emulsification, mixing, dispersion, vacuuming, heating, and cooling, being suitable for production such as cosmetics, skincare, food, chemicals, paint, and pharmaceuticals.
Precise Temperature Control: Furnished with heating and cooling systems, it enables users to regulate temperature and time, along with real-time monitoring and recording of material temperatures.
High-Quality and Hygienic Components: All contact parts are fabricated from SUS316L stainless steel, guaranteeing hygiene and conformity with GMP standards.
Efficient Mixing and Vacuum System: It is equipped with both high-shear and slow scraping mixers featuring variable speed control, along with a dry vacuum pump that can rapidly reach -0.09 MPa, guaranteeing the most favorable vacuum conditions
Specifications
| Item | Parameter |
|---|---|
| Emulsifying Main Pot | 20 L (Working Volume: 10 L) |
| Allowable Working Pressure | Inside Pot: -0.1 MPa; Jacket: 0.1 MPa |
| Allowable Working Temperature | ≤130℃ |
| Pre-treatment Pot | Oil Pot: 10 L; Water Pot: 10 L |
| Mixer Type | Turbine |
| Mixer Power | 180 W |
| Slow Frame Agitator | 0-60 R/min (Variable Frequency Control), 400 W |
| High-Speed Homogenizer | 0-3500 R/min (Variable Frequency Control), 750 W |
| Vacuum Degree | -0.09 MPa |
| Vacuum Pump | Power: 370 W, Type: Dry Type |
Machine Details
Mixer
Oil pan and water pan
Hydraulic system
