High-End Pharmaceutical Machinery Analysis – Capsule Counter & More

Capsule counter(SLDS-16D*2), bottle unscrambler and cleaner (Grand-200C), high-end desiccant sealer are part of Grand’s product range.In today’s competitive pharmaceutical industry, high-end machinery is essential. Automation boosts efficiency and improves product quality. In this article, we provide a comprehensive analysis of our high-end machinery products. Every piece of equipment is designed and manufactured according to national GMP standards and US FDA standards. These machines are a testament to our leadership in Pharmaceutical Machinery technology.

Our machines have been built for precision and reliability. They are ideal for pharmaceutical, food, health care, and other industries. In this post, we cover each product in detail. We also explain how our devices meet the highest industry standards while delivering outstanding performance.

I. Overview of Our High-End Machinery

Our state-of-the-art machinery is engineered to streamline production processes. Each machine is built with high automation and advanced control systems. The key features of our equipment include:

• Full Automation:Every machine uses PLC control and touchscreen interfaces. Parameters can be adjusted easily. Short, clear commands ensure fast responses.
• High Production Efficiency:Our machines are designed to work at high speeds. For example, the Bottle Unscrambling and Cleaning Machine can achieve up to 280 bottles per minute.
• Safety First:Safety features such as plexiglass guards, automatic door-stop functions, and multiple alarm systems protect operators.
• Environmental Protection:We use closed drive mechanisms and sealed transmission systems. This prevents lubricant leakage and reduces environmental pollution.
• Versatility:Our machines can adapt to various bottle shapes and packaging needs. There is no need to change molds for round, square, or flat bottles.
• Global Standards:All equipment complies with GMP and US FDA standards. This assures quality and safety in every process.

These features make our machines stand out in the world of Pharmaceutical Machinery. Whether you need a Bottle Unscrambling and Cleaning Machine or a Capsule & Tablet Counter, our products deliver precision, speed, and reliability.

II. Grand-200C High-End Bottle Unscrambling and Cleaning Machine

1. Product Introduction

The Grand-200C is a high-end bottle unscrambling and cleaning machine. It is engineered to sort and clean bottles with unmatched efficiency. This machine is built to meet both national GMP and US FDA standards. It uses a sophisticated PLC control system, and every parameter is adjustable through an intuitive touchscreen interface.

2. Key Features

Exceptional Production Speed:
The Grand-200C can process up to 280 bottles per minute. Fast production is critical for high-volume operations.

Enhanced Safety Design:
A robust plexiglass guard protects the operator. The door auto-stop function ensures that the machine halts when the safety door is opened. This design greatly minimizes the risk of accidents.

User-Friendly Operation:
A large storage hopper with an automatic door opening function reduces the need for frequent manual bottle loading. This reduces labor intensity.

Versatility in Bottle Handling:
Without the need to change molds, this machine can handle round, square, and flat bottles. It adapts easily to various packaging requirements.

Meets GMP Requirements:
An integrated air cleaning function guarantees that bottles are thoroughly cleaned. This is essential for maintaining product purity.

100% Bottle Quality Assurance:
With features like automatic bottle rejection, every bottle processed meets strict quality criteria.

3. Technical Specifications

• Maximum Production Capacity:60–280 bottles per minute
• Bottle Specifications:Diameter range from 30 mm to 150 mm
• Voltage/Frequency:AC200V / 50Hz
• Power:90 kW
• Compressed Air Requirement:3 Mpa
• Dimensions (L×W×H):3330 × 1150 × 1850 mm
• Weight:900 kg

This Grand-200C machine is a prime example of a high-end Bottle Unscrambling and Cleaning Machine. Its outstanding performance and versatile design make it an essential tool in any modern pharmaceutical production line.

III. Grand-200CII High-End Drying Agent Sealer Machine

1. Product Introduction

The Grand-200CII is a high-end drying agent sealer machine. It is designed to automatically insert drying agents into bottles. This process is crucial for maintaining product integrity and shelf life. The machine uses a combination of precise sensors and PLC control. Every parameter is adjustable via the touchscreen interface.

2. Key Features

1. Easy Adjustment:
   The machine easily adjusts to different thicknesses of drying agents. This solves the common issue of calibration difficulties in similar equipment.
2. Built-In Detection System:
   A drying agent non-insertion detection device enhances the quality control process. It increases the overall product qualification rate.
3. Safety Mechanisms:
   An automatic door-stop function is installed. This feature ensures operator safety by halting the machine when the door is opened.
4. Versatility:
   It can handle a wide range of bottle sizes. Suitable for bottles with diameters of 30–120 mm and heights of 30–200 mm.

The Grand-200CII machine represents a breakthrough in drying agent sealer technology. It is an excellent complement to our line of Pharmaceutical Machinery.

IV. SLDS-16D*2 Electronic Pill Counter – A Top Capsule & Tablet Counter

1. Product Introduction

The SLDS-16D*2 is an advanced electronic pill counter. It functions as a high-precision Capsule  Counter. The machine utilizes a modular design integrated with optical sensors and a microcomputer system. It is capable of counting tablets, capsules, round pills, and soft capsules with unmatched precision.

2. Key Features

Modular Design:
The device features a modular design that allows tool-free disassembly. This makes maintenance and cleaning quick and easy.

High Precision Counting:
A combination of optical and microcomputer systems guarantees counting accuracy within 0.1‰. This is vital in the pharmaceutical field.

Automatic Cleaning:
The pill counter has an automatic cleaning function for its counting heads. This ensures that dust and debris do not affect the sensor accuracy.

Error Rejection System:
The machine automatically rejects bottles with counting errors. This helps maintain a high quality control standard.

Low Noise Operation:
Thanks to a full-wave inverter and a vibration module with a spring design, the device operates at a noise level at least 10 dB lower than similar machines.

Safety Features:
Built-in sensors detect if the feed hopper is empty. The system triggers an automatic stop to prevent miscounts or machine damage.

User-Friendly Interface:
All parameters can be set via a full Chinese-language touchscreen. However, multilingual options are available to cater to global users.

3. Technical Specifications

• Vibratory Channel Count:16 × 2 (with 4 discharge chutes)
• Maximum Production Speed:Up to 20,000 tablets per minute (depending on pill size)
• Filling Range:1 to 9,999 tablets per bottle
• Pill Size Specifications:Thickness: 3–10 mm; Diameter: 3–20 mm; Length: 3–30 mm
• Bottle Diameter:20–200 mm
• Bottle Height:40–240 mm
• Voltage/Frequency:AC220V, 50/60Hz
• Power:5 kW
• Air Pressure:6 Mpa
• Dimensions (L×W×H):1580 × 2060 × 1770 mm
• Hopper Capacity:70 liters
• Weight:Approximately 700 kg

The SLDS-16D*2 is a state-of-the-art Capsule Counter. It is widely used in pharmaceutical production lines where precision and speed are essential. This machine ensures that every pill is counted correctly, thereby maintaining the high standards required in pharmaceutical manufacturing.
